Disc Harrow for Sale - Tractor Implements
The Offset Disc Harrow is designed with a heavier weight per disc, giving it superior penetration capability to break down large clods typically left after disc or chisel plowing in hard soil conditions. Built with a robust construction, it can be used as either a mounted or trailed implement, making it ideal for chopping and incorporating stubble and crop residues into the soil.
This Disc Harrow effectively prepares the seedbed, leaving the soil in a granular structure that promotes optimal plant growth. It enhances soil aeration, aids in moisture retention for extended periods, and helps control weeds.
In sandy loam soils, this implement can also serve as a primary tillage tool. The plowing depth is easily adjusted by modifying the offset angles of the gauges. Additionally, a simple pin removal allows for quick conversion between mounted and trailed positions.
Technical Specifications
Specifications | 14 Discs | 16 Discs |
No of Discs | 14 Discs | 16 Discs |
Disc Size | 61 cm (24") | 61 cm (24") |
Weight | 524 Kgs | 549 Kgs |
Working Width | 1.40 m | 1.50 m |
Tractor Compatibility | 50 hp | 60 - 85 hp |
Disc Diameter | 560 mm | 560 mm |
Disc Thickness | 4.5 mm | 4.5 mm |
No of Bearing | 4 | 4 |
